SFP Modules

Ethernet Direct offers hot-pluggable Ethernet SFP Modules ranging from 10GbE, Gigabit, and fast Ethernet interfaces. Digital-diagnostic-monitoring (DDM) feature provides user with critical information concerning the status of the transmitted and received signals. This approach allows for better fault isolation and error detection.



SFP-DD-SXLC-E

SFP 850nm, LC, Multi-mode, 0.55km with DDM

SFP-DD-LSXLC-2E

SFP 1310nm, LC, Single-mode, 2km with DDM

SFP-DD-LXLC-10E

SFP 1310nm, LC, Single-mode, 10km with DDM

SFP-DD-LHXLC-30E

SFP 1310nm, LC, Single-mode, 30km with DDM

SFP-DD-XDLC-50E

SFP 1550nm, LC, Single-mode, 50km with DDM

SFP-DD-ZXLC-70E

SFP 1550nm, LC, Single-mode, 70km with DDM

SFP-DD-EZXLC-90E

SFP 1550nm, LC, Single-mode, 90km with DDM

SFP-DD-EZXLC-120E

SFP 1550nm, LC, Single-mode, 120km with DDM

SFP-DD-GWDM1310-10E

WDM SFP 1310nm, LC, Single-mode, 10km with DDM, Multi-rate



SFP-DD-GWDM1550-10E

WDM SFP 1550nm, LC, Single-mode, 10km with DDM, Multi-rate

SFP-DD-GWDM1310-20E

WDM SFP 1310nm, LC, Single-mode, 20km with DDM, Multi-rate



SFP-DD-GWDM1550-20E

WDM SFP 1550nm, LC, Single-mode, 20km with DDM, Multi-rate

SFP-DD-GWDM1310-40E

WDM SFP 1310nm, LC, Single-mode, 40km with DDM, Multi-rate



SFP-DD-GWDM1550-40E

WDM SFP 1550nm, LC, Single-mode, 40km with DDM, Multi-rate

SFP-DD-GWDM1310-60E

WDM SFP 1310nm, LC, Single-mode, 60km with DDM, Multi-rate



SFP-DD-GWDM1550-60E

WDM SFP 1550nm, LC, Single-mode, 60km with DDM, Multi-rate

SFP-SXLC-E

SFP 850nm, LC, Multi-mode, 2km

SFP-LXLC-10E

SFP 1310nm, LC, Single-mode, 10km

SFP-LHXLC-30E

SFP 1310nm, LC, Single-mode, 30km

SFP-XDLC-50E

SFP 1550nm, LC, Single-mode, 50km

SFP-ZXLC-70E

SFP 1550nm, LC, Single-mode, 70km

Product Features

  • Compliant with IEEE 802.3z Gigabit Ethernet Standard
  • Compliant with Fiber Channel 100-SM-LC-L standard (WDM models only)
  • Multi-rate 125Mbps to 1.25Gbps (WDM models only)
  • Supports Digital Diagnostics Monitoring (DDM) funciton, and compliant with SFF8472
  • standard (only available for SFP-DD models)
  • Hot pluggable duplex LC connector
  • Hot pluggable simplex LC connector (WDM models only)
  • Industry standard small form pluggable (SFP) package
  • Differential LVPECL inputs and outputs
  • Single power supply 3.3V
  • TTL signal detecting indicator
  • Class 1 laser product complies with EN 60825-1
  • Supports extended temperature -40 to 85°C (E Models only)



SFP-FXMM-E

SFP, 1310nm, LC, Multi-mode,2km

SFP-FXSM-30E

SFP, 1310nm, LC, Single-mode,30km

SFP-FXSM-60E

SFP, 1310nm, LC, Single-mode,60km

SFP-WDM1310-20E

WDM SFP, 1310nm, LC, Single-mode,20km



SFP-WDM1550-20E

WDM SFP, 1550nm, LC, Single-mode,20km

Product Features

  • Compliant with Fast Ethernet standard
  • Compliant with IEEE 802.3ah 100Base-BX (WDM models only)
  • Compliant with ITU-T G.985 class S (WDM models only)
  • Hot pluggable duplex LC connector
  • Hot pluggable simplex LC connector (WDM models only)
  • Industry standard small form pluggable (SFP) package
  • Differential LVPECL inputs and outputs
  • Single power supply 3.3V
  • TTL signal detecting indicator
  • Class 1 laser product complies with EN 60825-1
  • Supports extended temperature -40 to 85°C (E Models only)
