Industrial Media Converters

Ethernet Direct offers industrial grade media converters for Gigabit Ethernet to fiber or Ethernet to fiber solutions. These converters are designed with two important features: Link Fault Pass Through and Link Loss Forwarding.

Gigabit / Ethernet to Fiber

RUE-111

Industrial 10/100Base-T(X) to 100Base-FX Multi-mode (SC) Fiber Media Converter

RUE-113

Industrial 10/100Base-T(X) to 100Base-FX Single-mode (SC) Fiber Media Converter

RUE-111CSEM02

Industrial 10/100Base-T(X) to 100Base-FX Multi-mode (SC-2km) Compact Ethernet to Fiber SC Media Converter, -40 to 80°C

RUE-111SENM02

Industrial 10/100Base-T(X) to 100Base-FX Multi-mode (SC-2km) Slim Ethernet to Fiber SC Media Converter, -40 to 80°C

RUE-112SENM02

Industrial 10/100Base-T(X) to 100Base-FX Multi-mode (ST-2km) Slim Ethernet to Fiber ST Media Converter, -40 to 80°C

RUE-113SENK30

Industrial 10/100Base-T(X) to 100Base-FX Single-mode (SC-30km) Slim Ethernet to Fiber SC Media Converter, -40 to 80°C

RUE-113SENK50

Industrial 10/100Base-T(X) to 100Base-FX Single-mode (SC-50km) Slim Ethernet to Fiber SC Media Converter, -40 to 80°C

RUE-114SENK30

Industrial 10/100Base-T(X) to 100Base-FX Single-mode (ST-30km) Slim Ethernet to Fiber ST Media Converter, -40 to 80°C

RUG-118GSEN

Industrial 10/100/1000Base-T(X) to 100/1000Base SFP Slim Gigabit Ethernet to Fiber SFP Media Converter, -20 to 80°C

Product Features

Ethernet Direct offers unmanaged industrial grade Fast Ethernet & Gigabit media converter that supports conversion between electrical and optical Ethernet. Simple DIP switch allows user to easy configure function settings such as full/half duplex, Link Fault Pass Through, Ethernet flow control (802.3x), selecting Switch Mode (store & forward) or Converter Mode (Jumbo frame Pass-through).

High Performance Network Switching Technology

Conversion between 10/100/1000Base-T(X) and 100/1000Base SFP Fiber cable interface
Conversion between 10/100Base-TX and 100Base-FX cable interface
Store-and-Forward mode and Pass through mode via DIP switch to set functions
Supports LFP (Link Fault Pass-through) and Jumbo frames pass through.

Reliable Power Design

Supports 12 to 48VDC redundant power input
Power reverse polarity protection and overload current protection

Robust Industrial Design

CE, FCC certified
EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
EN 50121-4 certified for Railway Applications (Track Side)
Robust industrial design case complies with IP30 housing standard
Supports operating temperature -10 to 70°C & extended temperature -40 or -20 to 80°C
DIN-Rail or optional wall mounting installation
