Industrial 10GbE Core Switches

Applications like intelligent transportation and automation requires combine data, voice, and video which demand high performance and high reliability. Ethernet Direct full gigabit backbone switches provide maximum flexibility to cater these applications to guarantee system reliability and network availability.

Ethernet Direct offers industrial standards core switches to cater the demands of next generation networks with primary focus on speed, flexibility, reliability and future proof.

Product Features

The Cheetah series industrial grade Ethernet core switches are engineered to cater advanced core networks with 10GbE upgradeability. These switches are equipped with 20 gigabit SFP ports plus 4 combo gigabit ports and a selection of 2 or 4 10G SFP+ ports, IP30 protection, fan-less design with redundant isolated power supplies.

High Performance Network Switching Technology

  • Industrial 24 x 100/1000Base SFP + 4 x 100/100Base SFP/RJ-45 + 4 x 10 GbE SFP Managed Ethernet Switch (CHMG-20842GP series)
  • Industrial 24 x 100/1000Base SFP + 4 x 100/100Base SFP/RJ-45 + 2 x 10 GbE SFP Managed Ethernet Switch (CHMG-20822GP series)
  • Supports various network redundant solutions, including Direct-Ring, Direct-Chain, Join-Ring, STP, RSTP, MSTP and ITU-T G.8032
  • Proprietary ultra high speed redundant technology with < 10ms recovery time @ 250 devices
  • Supports IEEE1588 PTP V2 for precise time synchronization, to operate in Ordinary-Boundary, Peer to Peer Transparent Clock, End to End Transparent Clock, Master, Slave mode by each port
  • Supports various network security solutions, Port and MAC based IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, SSL/SSH v2
  • Supports DHCP Server/Client/Relay/Snooping/Snooping option 82/Relay option 82
  • Network traffic priority, QoS, Traffic classification QoS, CoS, bandwidth control for Ingress/Egress, broadcast storm control, DiffServ
  • Supports IEEE802.1Q VLAN, MAC-based VLAN, IP Subnet-based VLAN, Protocol-based VLAN, VLAN translation, GVRP/MVRP
  • Supports IGMP/MLD snooping V1/V2/V3, IGMP Filtering/Throttling, IGMP query, IGMP proxy reporting, MLD snooping
  • Supports dynamic IEEE 802.3ad LACP Link Aggregation, Static Link Aggregation
  • Supports RMON, MIB II, Port mirroring, Syslog, IEEE802.1ab LLDP for network monitoring
  • Supports IPv6 Telnet server, ICMPv6
  • Supports CLI, Web based management, SNMP v1/v2c/v3, Telnet server for management
  • Supports firmware upgrade via TFTP & HTTP with redundant firmware option

Reliable Power Design

  • Redundancy isolated low voltage 24/48VDC, or/and isolated High voltage AC/DC (110/220 VAC/VDC) power inputs
  • Supports negative voltage power input with isolated RS-232 console port
  • Power reverse polarity protection and overload current protection

Robust Industrial Design

  • UL60950-1, CE, FCC certified
  • EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
  • EN 50121-4 certified for Railway Applications (Track Side)
  • Robust industrial design case complies with IP30 housing standard
  • Supports operating temperature -10 to 70°C
  • 19" rack mounting installation
