SyncE & IEEE 1588 PTP Switches
Ethernet Direct offers the Industry’s first switches to support Synchronous Ethernet (SyncE) and IEEE 1588 PTP protocols. SyncE and IEEE1588 PTP V2 are increasingly applied in mobile backhaul application where many devices are placed in outdoor cabinets. These switches support STP/RSTP/MSTP/ITU-T G.8032 ERPS, IGMP, VLAN, QoS ,Security ,IPv6, bandwidth control, port mirroring, cable diagnostic, Green Ethernet and more.
Product Features
- Complies with IEEE standards
- Provides multiple Gigabit TX ports with RJ-45 connector with supporting of Green Ethernet IEEE802.3az EEE (Energy Efficient Ethernet)
- Provides multiple Gigabit SFP slots with supporting of DDMI
- Supports various network redundant solutions, including Direct-Ring, Direct-Chain, Join-Ring, STP, RSTP, MSTP and ITU-T G.8032
- Proprietary ultra high speed redundant technology with < 10ms recovery time @ 250 devices
- Supports IEEE1588 PTP V2 for precise time synchronization, to operate in Ordinary-Boundary, Peer to Peer Transparent Clock, End to End Transparent Clock, Master, Slave mode by each port
- Supports various network security solutions, Port and MAC based IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, SSL/SSH v2
- Supports DHCP Server/Client/Relay/Snooping/Snooping option 82/Relay option 82
- Network traffic priority, QoS, Traffic classification QoS, CoS, bandwidth control for Ingress/Egress, broadcast storm control, DiffServ
- Supports IEEE802.1Q VLAN, MAC-based VLAN, IP Subnet-based VLAN, Protocol-based VLAN, VLAN translation, GVRP/MVRP
- Supports IGMP/MLD snooping V1/V2/V3, IGMP Filtering/Throttling, IGMP query, IGMP proxy reporting, MLD snooping
- Supports dynamic IEEE 802.3ad LACP Link Aggregation, Static Link Aggregation
- Supports RMON, MIB II, Port mirroring, Syslog, IEEE802.1ab LLDP for network monitoring
- Supports IPv6 Telnet server, ICMPv6
- Supports CLI, Web based management, SNMP v1/v2c/v3, Telnet server for management
- Supports firmware upgrade via TFTP & HTTP with redundant firmware option
Reliable Power Design
- Equipped with 12 to 48VDC redundant power inputs
- Supports negative voltage power input with isolated RS-232 console port
- Designed with 2.25K VDC Hi-pot isolation protection for Ethernet ports and power
- Power reverse polarity protection and overload current protection
Robust Industrial Design
- UL60950-1, CE, FCC certified
- EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
- EN 50121-4 certified for Railway Applications (Track Side)
- Robust industrial design case complies with IP30 housing standard
- Supports operating temperature -10 to 60°C & extended temperature -40 to 80°C
- DIN-Rail or optional wall mounting installation
