DIN-Rail Power Supplies

Ethernet Direct offers a wide selection of industrial DIN-rail universal power supplies.



MDR-4024 / MDR-4048

40W, 1.7A/0.83A DIN-Rail 24/48VDC power supply with universal 85-264VAC or 120-370VDC input; Class I, Div 2 Hazardous Locations T4; Wide Temperature -20~70°C

MDR-6024 / MDR-6048

60W, 2.5A/1.25A DIN-Rail 24/48VDC power supply with universal 85-264VAC or 120-370VDC input; Class I, Div 2 Hazardous Locations T4; Wide Temperature -20~70°C

NDR-7524 / NDR-7548

75W, 3.2A/1.6A DIN-Rail 24/48VDC power supply with universal 90-264VAC or 127-370VDC input; Slim Size; Wide Temperature -20~70°C

NDR-12024 / NDR-12048

120W, 5A/2.5A DIN-Rail 24/48VDC power supply with universal 90-264VAC or 127-370VDC input; Slim Size; Wide Temperature -20~70°C

NDR-24024 / NDR-24048

240W, 10A/5A DIN-Rail 24/48VDC power supply with universal 90-264VAC or 127-370VDC input; Wide Temperature -20~70°C

SDR-7524 / SDR-7548

75W, 3.2A/1.6A DIN-Rail 24/48VDC power supply with universal 88-264VAC or 124-370VDC input; Slim Size, 150% peak load capability; Wide Temperature -30~70°C

SDR-12024 / SDR-12048

120W, 5A/2.5A DIN-Rail 24/48VDC power supply with universal 88-264VAC or 124-370VDC input; Slim Size, 150% peak load capability; Wide Temperature -30~70°C

SDR-24024 / SDR-24048

240W, 105A/5A DIN-Rail 24/48VDC power supply with universal 88-264VAC or 124-370VDC input; 150% peak load capability; Wide Temperature -25~70°C

SDR-480P24 / SDR-480P48

480W, 20A/10A DIN-Rail 24/48VDC power supply with universal 90-264VAC or 127-370VDC input, Current share up to 3840W, 150% peak load capability; Wide Temperature -25~70°C

DR-4524

48W/2A DIN-Rail 24VDC power supply with universal 85-264VAC or 120-370VDC input; -10~50°C

DR-7524 / DR-7548

75W, 3.2A/1.6A DIN-Rail 24/48VDC power supply with universal 85-264VAC or 120-370VDC input; -10~60°C

DR-12024 / DR-12048

120W, 5A/2.5A DIN-Rail 24/48VDC power supply with universal 88-132VAC/176-264VAC or 248-370VDC input; -10~60°C

DRP-24024 / DRP-24048

240W, 10A/5A DIN-Rail 24/48VDC power supply with universal 85-264VAC input or 120-370VDC input; -10~70°C

DRP-48024 / DRP-48048

480W, 20A/10A DIN-Rail 24/48VDC power supply with universal 180-264VAC or 250-370VDC input; Wide Temperature -20~70°C

MDR-60 / MDR-40 Series

  • Plastic case, ultra slim
  • 1∅, full range input
  • No load power consumption<0.75W~1W
  • Assemble on industrial rail TS-35 / 7.5 or 15
  • Built-in active PFC function
  • DC OK relay contact
  • Class I, Div 2 Hazardous Locations T4

NDR-75 / NDR-120 / NDR-240 Series

  • Metal case, economical models
  • 1∅, full range input
  • Slim size, model width: 32 ~ 85.5mm
  • EMC EN55022 class B

SDR-75 / SDR-120 / SDR-240 / SDR-480P Series

  • 1∅, full range input
  • 94% high efficiency and complete functions
  • Built-in active PFC function (except SDR-75 Series)
  • Assemble on industrial rail TS-35 / 7.5 or 15
  • Built-in DC OK relay contact (except SDR-75 Series)
  • 150% peak load capability by models
  • Current sharing function (SDR-480P Series)

DR-45 / DR-75 / DR-120 / DRP-240 / DRP-480 Series

  • Metal case (except DR-45)
  • 1∅, full range or 115/230 VAC or 230 VAC only input range by models
  • Built-in active PFC function (240W~480W)
