IEC 61850 Managed Switches

Ethernet Direct offers IEC 61850 & IEEE 1613 certified Gigabit Ethernet managed switches specifically designed for power substation systems. These switches are equipped with redundant and isolated power supplies 24/48/-48VDC and 110/220VDC/VAC. The managed Ethernet functions include STP/RSTP/MSTP/ITU-T G.8032 ERPS, IGMP, VLAN, QoS, ACL, Security, IPv6, bandwidth control, port mirroring, cable diagnostic, Green Ethernet and more.



Product Features

Ethernet Direct offers IEC 61850 & IEEE 1613 certified Gigabit Ethernet managed switches specifically designed for power substation systems. These switches are equipped with redundant and isolated power supplies 24/48 VDC and 110/220 VDC/VAC and wide operating temperature -40~85°C

  • Complies with IEEE standards
  • Provides multiple Gigabit TX ports with RJ-45 connector with supporting of Green Ethernet IEEE802.3az EEE (Energy Efficient Ethernet)
  • Provides multiple Gigabit SFP slots with supporting of DDMI
  • Supports various network redundant solutions, including Direct-Ring, Direct-Chain, Join-Ring, STP, RSTP, MSTP and ITU-T G.8032
  • Proprietary ultra high speed redundant technology with < 10ms recovery time @ 250 devices
  • Supports GOOSE Message that complies with IEC61850 standard to achieve zero packet loss
  • Supports IEEE1588 PTP V2 for precise time synchronization, to operate in Ordinary-Boundary, Peer to Peer Transparent Clock, End to End Transparent Clock, Master, Slave mode by each port
  • Supports various network security solutions, Port and MAC based IEEE802.1X, RADIUS, ACL, TACACS+, HTTP/HTTPS, SSL/SSH v2
  • Supports DHCP Server/Client/Relay/Snooping/Snooping option 82/Relay option 82
  • Network traffic priority, QoS, Traffic classification QoS, CoS, bandwidth control for Ingress/Egress, broadcast storm control, DiffServ
  • Supports IEEE802.1Q VLAN, MAC-based VLAN, IP Subnet-based VLAN, Protocol-based VLAN, VLAN translation, GVRP/MVRP
  • Supports IGMP/MLD snooping V1/V2/V3, IGMP Filtering/Throttling, IGMP query, IGMP proxy reporting, MLD snooping
  • Supports dynamic IEEE 802.3ad LACP Link Aggregation, Static Link Aggregation
  • Supports RMON, MIB II, Port mirroring, Syslog, IEEE802.1ab LLDP for network monitoring
  • Supports IPv6 Telnet server, ICMPv6
  • Supports CLI, Web based management, SNMP v1/v2c/v3, Telnet server for management
  • Supports firmware upgrade via TFTP & HTTP with redundant firmware option

Reliable Power Design

  • Redundant isolated low voltage 24/48/-48VDC, or redundant isolated low voltage 24/48/-48VDC + isolated high voltage 110/220 VAC/VDC power inputs
  • Supports negative voltage power input with isolated RS-232 console port
  • Designed with 2.25K VDC Hi-pot isolation protection for Ethernet ports and power
  • Power reverse polarity protection and overload current protection

Robust Industrial Design

  • IEC 61850-3, IEEE1613 certified for power substation
  • UL60950-1, CE, FCC certified
  • EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
  • EN 50121-4 certified for Railway Applications (Track Side)
  • Robust industrial design case complies with IP30 housing standard
  • Supports operating temperature -40 to 85°C
  • DIN-Rail or optional wall mounting installation
