Industrial PoE Converters
Ethernet Direct offers a series of unmanaged Ethernet media converter that also injects PoE+ power through the RJ-45 port, and we providing a complete solution for your industrial Ethernet network.
CVE-111EAT
Industrial 10/100Base-T(X) to 100Base-FX Multi-mode (SC) PoE+ Converter, Power Budget 30W
CVE-112EAT
Industrial 10/100Base-T(X) to 100Base-FX Multi-mode (ST) PoE+ Converter, Power Budget 30W
Product Features
High Performance Network Switching Technology
- Complies with IEEE standards
- Conversion between 10/100/1000Base-T(X) and 100/1000Base SFP Fiber cable interface for CVG-118GEAT
- Conversion between 10/100Base-TX and 100Base-FX SC or ST Fiber interface for CVE-111EAT/CVE-112EAT/CVE-113EAT/CVE-114EAT
- Provideing DIP switch to setup these fucnitons:
- Switch on/off of alarm relay
- Switch on/off ofLFPT (Link Fault Pass Through)
- Seleciton of data process architecture (Pass through/store and forward)
- Seleciton of SFP speed (CVG-118GEAT)
- Switch on/off of PoE output
- Enable/Disable of remote PD rest
Reliable Power Design
- Supports 12/24/48VDC redundant power input with built-in very high efficiency booster to rise up 55 VDC for PoE output
- Regulated PoE output voltage (55VDC) to stabilize PoE device, and guarantee delivery PoE power distance to 100m
- Provides 1 port IEEE802.3af/802.3at PoE+ output, 30W per port
- Power reverse polarity protection and overload current protection
Robust Industrial Design
- UL60950-1, CE, FCC certified
- EN 61000-6-2 and EN 61000-6-4 certified to use in heavy industrial environment
- EN 50121-4 certified for Railway Applications (Track Side)
- Robust industrial design case complies with IP30 housing standard
- Supports operating temperature -20 to 75°C
- DIN-Rail or optional wall mounting installation
